A12x25 PWM chromax.black.swap
FAN Specification
Size
120x120x25 mm
Mounting hole spacing
105x105 mm
Connector & pin-configuration
4-pin PWM
Cable length
1cm + 30cm NA-EC1 extension cable
Bearing
SSO2
Blade geometry
A-Series with Flow Acceleration Channels
Frame technology
AAO (Advanced Acoustic Optimisation)
Material
Sterrox® LCP
Rotational speed (+/- 10%)
2000 RPM
Min. rotational speed (PWM, +/-20%)
450 RPM
Airflow
102,1 m³/h
Acoustical noise
22,6 dB(A)
Static pressure
2,34 mm H₂O
Max. input power
1,68 W
Max. input current
0,14 A
Operating voltage
12 V
Voltage PWM signal
5 V
MTTF
> 150.000 h
Scope of delivery
4x NA-AVP1 chromax.black anti-vibration pads
4x NA-AVP1 chromax.blue anti-vibration pads
4x NA-AVP1 chromax.green anti-vibration pads
4x NA-AVP1 chromax.red anti-vibration pads
4x NA-AVP1 chromax.white anti-vibration pads
4x NA-AVP1 chromax.yellow anti-vibration pads
4x NA-AVP1 grey anti-vibration pads
NA-AVG1 chromax.black anti-vibration gasket for water cooling radiators
Fan screws
Warranty 6 years
