NF-S12A PWM chromax.black.swap
FAN Specification
Size
120x120x25 mm
Mounting hole spacing
105x105 mm
Connector & pin-configuration
4-pin PWM
Cable length
1cm + 30cm NA-EC1 extension cable
Bearing
SSO2
Blade geometry
S-Series with Anti-Stall Knobs
Frame technology
AAO (Advanced Acoustic Optimisation)
Rotational speed (+/- 10%)
1200 RPM
Min. rotational speed (PWM, +/-20%)
300 RPM
Airflow
107,5 m³/h
Acoustical noise
17,8 dB(A)
Static pressure
1,19 mm H₂O
Max. input power
1,44 W
Max. input current
0,12 A
Operating voltage
12 V
MTTF
> 150.000 h
Scope of delivery
4x NA-AVP1 chromax.black anti-vibration pads
4x NA-AVP1 chromax.blue anti-vibration pads
4x NA-AVP1 chromax.green anti-vibration pads
4x NA-AVP1 chromax.red anti-vibration pads
4x NA-AVP1 chromax.white anti-vibration pads
4x NA-AVP1 chromax.yellow anti-vibration pads
4x fan screws
Warranty
6 years
